LOMR
The SCADAWATT LOMR-07H product triggers its relays in the event of a grid fault. The relay outputs, when used with control panels, aim to disconnect the connection between the facility and the grid. This prevents energy produced at the facility from being sent to the grid and/or protects the devices used at the facility from potential damage due to grid issues.
- - Monitoring of voltage and frequency in single and three-phase grids
- - Over/under voltage and over/under frequency monitoring
- - Threshold settings for over/under voltage and over/under frequency
- - True RMS measurement principle
- - 3 programmable digital inputs
- - 3 programmable relay outputs
- - Intermittent neutral detection
- - OLED display
- - Remote monitoring via Modbus communication
- - Alarm feature through relay
| Operating Temperature | -40°C ~ 85°C |
| Protection Class | IP30 |
| Power Supply Voltage | 7-32 V |
| Mounting | DIN |
| Dimensions | 88 x 105 x 53 mm |
| Phase-to-Phase Measurement Range | 0-680 VAC |
| Phase-to-Neutral Measurement Range | 0-400 VAC |
| Frequency Measurement Range | 40-60 Hz |
| Communication | RS485 Modbus |
| Relay Output | 3 Units 8A/250 VAC |
